Main Application
• 2-Layers and 3-Layers Flexible Copper Clad Laminate.(FCCL)Product Specification
| Item | Unit | Value | Test Method | |||
| Nominal Thickness | µm | 9 | 12 | 18 | - | |
|
Thickness by weight |
g/m² | 79±5% | 107±5% | 153±5% | IPC-TM650 | |
| Purity | % | ≧99.8 | ≧99.8 | ≧99.8 | IPC-TM650 | |
| Tensile Strength | at RT | kg/mm² | ≧28 | ≧28 | ≧28 | IPC-TM-650 |
| at 180℃ | kg/mm² | ≧10 | ≧10 | ≧10 | ||
| Elongation | at RT | % | ≧2 | ≧2 | ≧2 | IPC-TM-650 |
| at 180℃ | % | ≧3 | ≧5 | ≧8 | ||
| Ronghness of Shiny side (Ra) | µm | ≦0.43 | ≦0.43 | ≦0.43 | IPC-TM-650 | |
| Ronghness of Matte side (Rz) | µm | ≦3.0 | ≦3.0 | ≦3.0 | IPC-TM-650 | |
