Main Application
• Anode material for secondary Li-ion battery.Product Specification
| Item | Unit | Value | Test Method | |||||
| Nominal Thickness | µm | 8 | 10 | 12 | 15 | 20 | - | |
|
Thickness by weight |
g/m² | 72±5% | 89±5% | 105±5% | 133±5% | 178±5% | IPC-TM650 | |
| Tensile Strength | at RT | kg/mm² | ≧28 | ≧28 | ≧28 | ≧28 | ≧28 | IPC-TM-650 |
| Elongation | at RT | % | ≧3 | ≧3 | ≧3 | ≧3 | ≧3 | IPC-TM-650 |
| Ronghness of Shiny side (Ra) | µm | ≦2.0 | ≦2.0 | ≦2.0 | ≦2.0 | ≦2.0 | IPC-TM-650 | |
| Ronghness of Matte side (Rz) | µm | ≦2.0 | ≦2.0 | ≦2.0 | ≦2.0 | ≦2.0 | IPC-TM-650 | |
