Main Application
• Metal Core Printed Circuit Board.(MCPCB)Product Specification
| Item | Unit | Value | |
|
Refining |
O、H32 | ||
| Thickness | 10⁻⁶/℃ | 0.5-2.5(±0.01mm) built-to-order | |
|
Size |
mm | built -to-order(±2mm)) | |
| Tensile Strength | 0 | Kg/mm² | 14 |
| H32 | Kg/mm² | 16 | |
| Yield Strength | 0 | Kg/mm² | 6 |
| H32 | Kg/mm² | 14 | |
| Elongation | 0 | % | 30 |
| H32 | % | 18 | |
| Specific Heat(10~100℃) | cal/g.℃ | 0.23 | |
| CTE(20-100℃) | 10⁻⁶/℃ | 23.4 | |
| Thermal Conductivity(25℃) | cal/cm.s.℃ | 0.33 | |
Chemical Composition(%)
| Si | Fe | Cu | Mn | Mg | Cr | Zn |
Other |
Al | |
| Each | TOT | ||||||||
| ≦0.25 | ≦0.4 | ≦0.1 | ≦0.05 | 2.2~2.8 | 0.15~0.35 | ≦0.1 | ≦0.05 | ≦0.15 | Other |
