Main Application
• Metal Core Printed Circuit Board.(MCPCB)Product Specification
| Item | Unit | Value | |
|
Refining |
O、T6 | ||
| Thickness | 10⁻⁶/℃ | 0.5-2.5(±0.01mm) built-to-order | |
|
Size |
mm | built -to-order(±2mm)) | |
| Tensile Strength | 0 | Kg/mm² | 5.5 |
| T6 | Kg/mm² | 28 | |
| Yield Strength | 0 | Kg/mm² | 12.5 |
| T6 | Kg/mm² | 31.5 | |
| Elongation | 0 | % | 25 |
| T6 | % | 12 | |
| Specific Heat(10~100℃) | cal/g.℃ | 0.22 | |
| CTE(20-100℃) | 10⁻⁶/℃ | 23.6 | |
| Thermal Conductivity(25℃) | cal/cm.s.℃ | 0.37 | |
Chemical Composition(%)
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti |
Other |
Al | |
| Each | TOT | |||||||||
| ≦0.25 | ≦0.4 | ≦0.1 | ≦0.05 | 2.2~2.8 | 0.15~0.35 | ≦0.1 | ≦0.15 | ≦0.05 | ≦0.05 | Other |
