Main Application
• The CCL,PCB and any other high temperature laminating equipment.Product Specification
| Item | Unit | Value |
| Hardness | HV | 480±30 |
|
CTE(0~100℃) |
10⁻⁶/℃ | 10.8 |
|
CTE(0~400℃) |
10⁻⁶/℃ | 11.3 |
| Thickness | mm | 1.0~2.0 |
| Length | mm | 4000 |
| Width | mm | 1295 |
|
Roughness(Ra) |
µm | <0.2 built-to-order |
| Planeness | mm/M | ≦3 |
|
Thichness tolerance |
mm | <0.05 |
|
Dimensional tolerance |
mm | +2/-0 |
|
Diagonal tolerance |
mm | <2 |
Chemical Composition(%)
| C | Si | Mn | P | S | Ni | Cr | Cu | Nb |
| ≦0.07 | ≦1.00 | ≦1.00 | ≦0.04 | ≦0.03 | 3.00~5.00 | ≧15.00 | 3.00~5.00 | 0.15~0.45 |
Mechanical Properties
| Yield Strength (N/mm²) | Tensile Strength (N/mm²) | Elongation (%) | Hardness (HV) |
| 1370 | 1370 | 7 | 480±30 |
Physical Composition(%)
| Density(g/cm3) | Specific Heat(Cal/cm.s.℃) | CTE(x10-6/℃) |
| 7.8 | 0.043 | 11.1~11.6 |
